Features

• Pressure switches are used to monitor chamber sump water level; If pressure switch and/or temperature sensor failure occurs, alarm sounds and message is printed
• Color touch screen microprocessor control system
• Compact space saving footprint
• Effective, fast and energy efficient cycles
• Ability to flush up to six lumened instruments per load
• Manual drop-down glass doors
• Stainless-steel pump provides circulation using a 3 HP (2.2 kW) motor with up to 22 psig (151 kPa) at pump outlet; pump motor is equipped with overload protection and sealed bearings (requiring no periodic lubrication)
• Stainless-steel construction; unit drains between rinses to minimize residue remaining on instruments; to help prevent bacterial contamination, unit drains completely between cycles
• Manifold racks are equipped with rotary spray arms positioned to reach all load surfaces; removable end-tips ensure easy spray arm cleaning and maintenance
• Electric heating element (three 4 kW, 12 kW total) in bottom of chamber (sump) raise and maintain water temperature up to 180°F (82°C) during Wash cycle and up to 194°F (90°C) during thermal rinse cycle
• Removable stainless-steel filter in chamber sump prevents debris from entering pump
• Wash chamber is constructed of argon welded 20 Gauge, #304 L, stainless steel (No.4 finish); chamber inhibits corrosive action of detergent, and is easy to clean, with no enameled surfaces to chip or crack should an object be accidentally dropped in chamber
• Chemical injection pumps (three) are located in lower portion of washer/disinfector. Pumps allow use of Prolystica® 2X concentrate cleaning products; Each concentrated product is two times the concentration of a traditional product, therefore two times less chemical is injected to properly process cycles
• High-capacity air blower delivers heated (240°F [116°C]) fresh air through unit piping and manifold rack to promote complete drying; fresh air is drawn through a HEPA filter
• Microprocessor control system is equipped with a touch screen customer interface; this 5.7 Inch (115 mm) color touch screen is mounted at eye level above chamber on load side, allowing easy monitoring of all wash cycles
• Removable front service panels provide easy access to all piping, valves, electrical components and wiring; servicing from sides of unit is not required
• A vented unit is supplied; chamber vapors are exhausted to the building exhaust system through a 4.0 Inch (102 mm) OD vent connection located on top of washer
• Drain discharge cool down ensures water drained at end of each phase, from chamber sump to building drain system, does not exceed 140°F (60°C); If water temperature in sump is higher than 140°F (60°C), cold water is automatically added to reduce water temperature discharged into building drain system
• Electrical control box is fan cooled to extend components life expectancy

  McKesson #	970932
  Manufacturer #	FH120101
  Brand	Amsco® 2532
  Manufacturer	Steris
  Country of Origin	Canada
  Application	Single Chamber Washer / Disinfector
  Buy American Act (BAA) Compliant	No
  Chamber Dimensions	25 X 25-1/4 X 25-1/2 Inch Chamber
  Door Type	Bottom Hinged Door
  Overall Dimensions	28-1/2 X 28-1/2 X 78 Inch
  Trade Agreement Act (TAA) Compliant	No
  UNSPSC Code	42281530
  Unwrapped Cycle Time	30 Minutes
  Volume	604 Liter
